Thread: Top Metal thickness

10 Discord messages from ℹ️ - Information/⁉️-questions/threads/top-metal-thickness.md.

Category: ℹ️ - Information Parent channel: #⁉️-questions Thread ID: 1423053988210675852

Messages: 10

message-1423053988210675852

2025-10-01T21:08:29.854+00:00 — tnt (@246tnt)

Content

What's the top metal layer thickness in `gf180mcuD` ? I though this was the `Top metal (30kA)` but looking at the tech lef, it doesn't seem to match any of the available option.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423067312193404959

2025-10-01T22:01:26.539+00:00 — htamas (@h.tamas)

Content

From https://github.com/RTimothyEdwards/open_pdks/blob/master/gf180mcu/NOTES:
"February 14, 2023:  Added PDK variant gf180mcuD, which is like gf180mcuC except has a top metal thickness of 1.1um instead of 0.9um.  According to GF, this is preferred for better wire bonding yield on the pads.  The first open MPW was done with gf180mcuC, but all subsequent open MPWs will be done with gf180mcuD."
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/1-B2132.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423067907574726676

2025-10-01T22:03:48.489+00:00 — htamas (@h.tamas)

Content

See also https://github.com/RTimothyEdwards/open_pdks/blob/master/gf180mcu/Makefile.in#L60-L63 and the text above it
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/1-B2132.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423076158219489300

2025-10-01T22:36:35.596+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

@Tim Edwards
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-10_media/6bcc8e61db497b620550682309ace5d5-D89B4.png",
        "color": null,
        "discriminator": "0000",
        "id": "1365118310701600900",
        "isBot": false,
        "name": "rtimothyedwards_19428",
        "nickname": "Tim Edwards",
        "roles": []
      }
    ]
  }
}
</details>

message-1423076484469362820

2025-10-01T22:37:53.38+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

Attachments

<details> <summary>Attachments data</summary>
[
  {
    "fileName": "image.png",
    "fileSizeBytes": 226606,
    "id": "1423076484163043451",
    "url": "2025-10_media/image-2F3E9.png"
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423076573749313630

2025-10-01T22:38:14.666+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

> We are using the B option @ https://gf180mcu-pdk.readthedocs.io/en/latest/analog/layout/inter_specs/inter_specs_3_43.html

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 1,
    "emoji": {
      "code": "ok_hand",
      "id": "",
      "imageUrl": "2025-10_media/1f44c-59547.svg",
      "isAnimated": false,
      "name": "👌"
    },
    "users": [
      {
        "avatarUrl": "2025-10_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
        "color": null,
        "discriminator": "0000",
        "id": "596068704471482370",
        "isBot": false,
        "name": "246tnt",
        "nickname": "tnt"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423076653290094675

2025-10-01T22:38:33.63+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

> 1.1um (a.k.a. 11 kiloAngstroms).
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423076708701175890

2025-10-01T22:38:46.841+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

Guess that should be published somewhere.......
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423178688215777411

2025-10-02T05:24:00.652+00:00 — tnt (@246tnt)

Content

Thanks!
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1423197422867447882

2025-10-02T06:38:27.341+00:00 — tnt (@246tnt)

Content

A bit unfortunate that it's the "B" option because MiM won't be available in TT  (user don't have access to the top metal layer, so they can't contact the top plate), but "c'est la vie".

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 1,
    "emoji": {
      "code": "smiling_face_with_tear",
      "id": "",
      "imageUrl": "2025-10_media/1f972-F415D.svg",
      "isAnimated": false,
      "name": "🥲"
    },
    "users": [
      {
        "avatarUrl": "2025-10_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
        "color": null,
        "discriminator": "0000",
        "id": "323371864074485771",
        "isBot": false,
        "name": "mole99",
        "nickname": "mole99"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-10_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>
