Thread: SRAM rules

10 Discord messages from ℹ️ - Information/⁉️-questions/threads/sram-rules.md.

Category: ℹ️ - Information Parent channel: #⁉️-questions Thread ID: 1444023934251962418

Messages: 10

message-1444023934251962418

2025-11-28T17:55:34.593+00:00 — tnt (@246tnt)

Content

Are the SRAM rules only valid for foundry provided cell ? What if I want to design my own memory array or dual port cell or stuff like that, can I use them ?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1444043397395648593

2025-11-28T19:12:54.968+00:00 — Leo Moser (mole99) (@mole99)

Content

Yes, I think that should be possible.
Afaik it's not the cells that are detected, but rather the SRAM marker layer.
However, as you probably know, there's no guarantee your cells will work after production, since the SRAM cells in the PDK were probably carefully designed to violate the normal core rules.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
    "discriminator": "0000",
    "isBot": false,
    "roles": [
      {
        "color": null,
        "id": "1423020172595298314",
        "name": "Mod",
        "position": 4
      }
    ]
  },
  "message": {}
}
</details>

message-1444043702996697158

2025-11-28T19:14:07.829+00:00 — Leo Moser (mole99) (@mole99)

Content

In fact, @Tim Edwards  already shrinked the 5V SRAM cells.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
    "discriminator": "0000",
    "isBot": false,
    "roles": [
      {
        "color": null,
        "id": "1423020172595298314",
        "name": "Mod",
        "position": 4
      }
    ]
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-11_media/6bcc8e61db497b620550682309ace5d5-D89B4.png",
        "color": null,
        "discriminator": "0000",
        "id": "1365118310701600900",
        "isBot": false,
        "name": "rtimothyedwards_19428",
        "nickname": "Tim Edwards",
        "roles": []
      }
    ]
  }
}
</details>

message-1444043966369632256

2025-11-28T19:15:10.622+00:00 — tnt (@246tnt)

Content

I know he did but they are still 6T cells, I'm thinking about doing the same register file that I did on sky130, or a dual port cell, or rom or other things like that.

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 1,
    "emoji": {
      "code": "open_mouth",
      "id": "",
      "imageUrl": "2025-11_media/1f62e-FE396.svg",
      "isAnimated": false,
      "name": "😮"
    },
    "users": [
      {
        "avatarUrl": "2025-11_media/6f21ec45bc9221220509b769f634344b-E96BD.png",
        "color": null,
        "discriminator": "0000",
        "id": "840182560252624916",
        "isBot": false,
        "name": "logic_destroyer",
        "nickname": "asic destroyer"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1444044603459108975

2025-11-28T19:17:42.516+00:00 — Leo Moser (mole99) (@mole99)

Content

Yes, as long as you place the SRAM marker layer you can use the SRAM 3.3V/5V rules, as I understand it.

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 2,
    "emoji": {
      "code": "thumbsup",
      "id": "",
      "imageUrl": "2025-11_media/1f44d-27259.svg",
      "isAnimated": false,
      "name": "👍"
    },
    "users": [
      {
        "avatarUrl": "2025-11_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
        "color": null,
        "discriminator": "0000",
        "id": "596068704471482370",
        "isBot": false,
        "name": "246tnt",
        "nickname": "tnt"
      },
      {
        "avatarUrl": "2025-11_media/6f21ec45bc9221220509b769f634344b-E96BD.png",
        "color": null,
        "discriminator": "0000",
        "id": "840182560252624916",
        "isBot": false,
        "name": "logic_destroyer",
        "nickname": "asic destroyer"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
    "discriminator": "0000",
    "isBot": false,
    "roles": [
      {
        "color": null,
        "id": "1423020172595298314",
        "name": "Mod",
        "position": 4
      }
    ]
  },
  "message": {}
}
</details>

message-1444094873014898879

2025-11-28T22:37:27.712+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

When using the SRAM cells DRC rules there are normally a bunch of requirements around the layout of the cells that are not specified in DRC decks and such.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1444095064996446209

2025-11-28T22:38:13.484+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

My understanding is that they can violate the rules due to the tuning to make the regular patterns print better.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1444231058567467070

2025-11-29T07:38:36.878+00:00 — Leo Moser (mole99) (@mole99)

Content

These rules are documented here:
- https://gf180mcu-pdk.readthedocs.io/en/latest/physical_verification/design_manual/drm_11_1.html
- https://gf180mcu-pdk.readthedocs.io/en/latest/physical_verification/design_manual/drm_11_2.html

So it should be possible to submit your own custom cells based on these rules, but there is no guarantee that they will work as expected.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
    "discriminator": "0000",
    "isBot": false,
    "roles": [
      {
        "color": null,
        "id": "1423020172595298314",
        "name": "Mod",
        "position": 4
      }
    ]
  },
  "message": {}
}
</details>

message-1444370539190812773

2025-11-29T16:52:51.65+00:00 — Tim Edwards (@rtimothyedwards_19428)

Content

Since I created the 3.3V SRAM core cell myself, we'll put that theory to the test.

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 2,
    "emoji": {
      "code": "open_mouth",
      "id": "",
      "imageUrl": "2025-11_media/1f62e-FE396.svg",
      "isAnimated": false,
      "name": "😮"
    },
    "users": [
      {
        "avatarUrl": "2025-11_media/59486f73932f21d0f005985411cfae98-091E8.png",
        "color": null,
        "discriminator": "0000",
        "id": "684463118709162093",
        "isBot": false,
        "name": "chaask",
        "nickname": "chasak"
      },
      {
        "avatarUrl": "2025-11_media/6f21ec45bc9221220509b769f634344b-E96BD.png",
        "color": null,
        "discriminator": "0000",
        "id": "840182560252624916",
        "isBot": false,
        "name": "logic_destroyer",
        "nickname": "asic destroyer"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-11_media/6bcc8e61db497b620550682309ace5d5-D89B4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1444505562740953220

2025-11-30T01:49:23.773+00:00 — Tim 'mithro' Ansell (@mithro_)

Reply/reference

<details> <summary>Reference data</summary>
{
  "channelId": "1444023934251962418",
  "guildId": "1361349522684510449",
  "messageId": "1444370539190812773"
}
</details>

Content

Yeap! I'm interested to see how things go, I don't quite have the same pull with GF now I'm not Google.
