Thread: Failing Hold Checks

22 Discord messages from ℹ️ - Information/⁉️-questions/threads/failing-hold-checks.md.

Category: ℹ️ - Information Parent channel: #⁉️-questions Thread ID: 1445866342438932643

Messages: 22

message-1445866342438932643

2025-12-03T19:56:38.935+00:00 — Trevor Peyton (@trev5514)

Content

Has anyone been able to pass timing for hold checks on an 11MHz+ design? I have done everything I could think of, yet the corners still end up failing. The path is always pad -> reg nothing else.

I've tried these settings:

PL_RESIZER_HOLD_SLACK_MARGIN from 0.1, 0.3, 0.5 even 0.7 and none seem to make a difference (I do get less hold errors but all still fail)
I've tried PL_RESIZER_ALLOW_SETUP_VIOS

and

set_input_delay -min 0, .5, 1, 1.5

Any ideas?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445869250244902994

2025-12-03T20:08:12.21+00:00 — Leo Moser (mole99) (@mole99)

Content

Perhaps an unbalanced clock tree? You can view the clock tree in OpenROAD GUI.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
    "discriminator": "0000",
    "isBot": false,
    "roles": [
      {
        "color": null,
        "id": "1423020172595298314",
        "name": "Mod",
        "position": 4
      }
    ]
  },
  "message": {}
}
</details>

message-1445870302926999744

2025-12-03T20:12:23.189+00:00 — Lofty (@ravenslofty)

Reply/reference

<details> <summary>Reference data</summary>
{
  "channelId": "1445866342438932643",
  "guildId": "1361349522684510449",
  "messageId": "1445866342438932643"
}
</details>

Content

sure; I've passed hold checks on a 60MHz design :p
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-12_media/2-ADBB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "805909190333038612",
        "isBot": false,
        "name": "trev5514",
        "nickname": "Trevor Peyton",
        "roles": []
      }
    ]
  }
}
</details>

message-1445870444174376973

2025-12-03T20:12:56.865+00:00 — Lofty (@ravenslofty)

Content

I do often need to ECO some hold buffers in though
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445871889712021636

2025-12-03T20:18:41.508+00:00 — Trevor Peyton (@trev5514)

Content

With the exception of the right spot which I'll look into it looks very balanced.

Attachments

<details> <summary>Attachments data</summary>
[
  {
    "fileName": "Screenshot_2025-12-03_at_3.17.55_PM.png",
    "fileSizeBytes": 81870,
    "id": "1445871889535996176",
    "url": "2025-12_media/Screenshot_2025-12-03_at_3.17.55_PM-42947.png"
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445872139713511555

2025-12-03T20:19:41.113+00:00 — Trevor Peyton (@trev5514)

Reply/reference

<details> <summary>Reference data</summary>
{
  "channelId": "1445866342438932643",
  "guildId": "1361349522684510449",
  "messageId": "1445870444174376973"
}
</details>

Content

Do you manually place them in? Did you change your input/output delays or do you use the templates default 0 for min?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
        "color": null,
        "discriminator": "0000",
        "id": "1187141985530818611",
        "isBot": false,
        "name": "ravenslofty",
        "nickname": "Lofty",
        "roles": []
      }
    ]
  }
}
</details>

message-1445872535160885409

2025-12-03T20:21:15.395+00:00 — Lofty (@ravenslofty)

Reply/reference

<details> <summary>Reference data</summary>
{
  "channelId": "1445866342438932643",
  "guildId": "1361349522684510449",
  "messageId": "1445872139713511555"
}
</details>

Content

read `54-openroad-stapostpnr/summary.rpt` to find the failing corners, then look at `54-openroad-stapostpnr/<corner>/min.rpt` to find the failing paths, and then [follow the docs](https://librelane.readthedocs.io/en/latest/usage/using_ecos.html)
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-12_media/2-ADBB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "805909190333038612",
        "isBot": false,
        "name": "trev5514",
        "nickname": "Trevor Peyton",
        "roles": []
      }
    ]
  }
}
</details>

message-1445872687925690498

2025-12-03T20:21:51.817+00:00 — Lofty (@ravenslofty)

Content

it's manual in that you have to point the tooling at the cell you want to insert a hold buffer for, but there's no physical placement or such

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 2,
    "emoji": {
      "code": "clap",
      "id": "",
      "imageUrl": "2025-12_media/1f44f-3D381.svg",
      "isAnimated": false,
      "name": "👏"
    },
    "users": [
      {
        "avatarUrl": "2025-12_media/a894465ce64c0d99a11e309c80c403db-DA6C3.png",
        "color": null,
        "discriminator": "0000",
        "id": "228329196504481793",
        "isBot": false,
        "name": "nxmq99",
        "nickname": "nxmq99"
      },
      {
        "avatarUrl": "2025-12_media/2-ADBB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "805909190333038612",
        "isBot": false,
        "name": "trev5514",
        "nickname": "Trevor Peyton"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445873529651204217

2025-12-03T20:25:12.5+00:00 — Trevor Peyton (@trev5514)

Content

Thank you, I have been looking at those corners but I didn't know about the ECO step!
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445873775194279936

2025-12-03T20:26:11.042+00:00 — Lofty (@ravenslofty)

Content

(the downside of having a 60MHz design is that I have basically given up on meeting slow corner setup without major cheating)
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445874188090081450

2025-12-03T20:27:49.484+00:00 — Trevor Peyton (@trev5514)

Content

My original target was 90MHz and now I'm just trying to get any passing. I'm currently failing 10MHz...
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445874418621485189

2025-12-03T20:28:44.447+00:00 — Lofty (@ravenslofty)

Content

are you using the 9-track libraries?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445875058063970425

2025-12-03T20:31:16.902+00:00 — Trevor Peyton (@trev5514)

Content

Whatever the default one is.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445875652225011933

2025-12-03T20:33:38.561+00:00 — Lofty (@ravenslofty)

Content

7-track. Try adding `STD_CELL_LIBRARY: gf180mcu_fd_sc_mcu9t5v0` to your `librelane/config.yaml`

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 1,
    "emoji": {
      "code": "thumbsup",
      "id": "",
      "imageUrl": "2025-12_media/1f44d-27259.svg",
      "isAnimated": false,
      "name": "👍"
    },
    "users": [
      {
        "avatarUrl": "2025-12_media/2-ADBB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "805909190333038612",
        "isBot": false,
        "name": "trev5514",
        "nickname": "Trevor Peyton"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445876161984069644

2025-12-03T20:35:40.097+00:00 — Trevor Peyton (@trev5514)

Content

I'll give it a go after I try ECO. Surely 10MHz is possible with the 7-track? At this point - what do I know haha!
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445881315307159684

2025-12-03T20:56:08.745+00:00 — Trevor Peyton (@trev5514)

Content

@Lofty Did you ever run into unconnected ECO pins after the eco step?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2025-12_media/dd665ae27be32531af89aeb08fd05e04-1D5A4.png",
        "color": null,
        "discriminator": "0000",
        "id": "1187141985530818611",
        "isBot": false,
        "name": "ravenslofty",
        "nickname": "Lofty",
        "roles": []
      }
    ]
  }
}
</details>

message-1445884346933186621

2025-12-03T21:08:11.541+00:00 — Trevor Peyton (@trev5514)

Content

Looks like the disconnected pins are pwr/gnd: eco_buffer_0/VDD, eco_buffer_0/VNW, eco_buffer_0/VPW, and eco_buffer_0/VSS
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445885538736541748

2025-12-03T21:12:55.689+00:00 — Greg (@greg.hashtag.9468)

Content

What does your I/O connect to? If it's not actually driven synchronously alongside your clock input. You may be able to further relax the timing.
With a `input_delay -min 0` you're telling the tools, the external i/o arrives with the clock. So it tries to add 4ns of delay to ensure a leaf in your clock tree.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/fb1d1a9872c8ef9ce08855c75f2963a7-A225D.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445885936578728008

2025-12-03T21:14:30.542+00:00 — Trevor Peyton (@trev5514)

Content

Everything is synchronous with the clock input.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445907135476011179

2025-12-03T22:38:44.753+00:00 — BreakingTaps (@polyfractal)

Content

(oof, did not know about ECO or 9T stuff either. probably would have saved a lot of agony fussing with settings 😅 )
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/8d8c1d8b8ad51d6cdb1a47512c39b297-42908.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "inlineEmojis": [
      {
        "code": "sweat_smile",
        "id": "",
        "imageUrl": "2025-12_media/1f605-42B43.svg",
        "isAnimated": false,
        "name": "😅"
      }
    ]
  }
}
</details>

message-1445907388228960383

2025-12-03T22:39:45.014+00:00 — Trevor Peyton (@trev5514)

Content

Maybe, ECO isn't working for me still and neither is the 9T
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1445910109375959070

2025-12-03T22:50:33.786+00:00 — Trevor Peyton (@trev5514)

Content

For anyone that runs into the ECO issue:

"+OpenROAD.DetailedRouting": "Odb.InsertECOBuffers"
 "+Odb.InsertECOBuffers": "OpenROAD.DetailedRouting"

I haven't confirmed yet, but I added the Odb.InsertECOBuffers step but I didn't add the routing after which likely left the ECO buffers unconnected.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2025-12_media/2-ADBB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>
