Thread: Anybody thought of 1-2 mm² slot to be packaged SOIC-8 package?

10 Discord messages from ℹ️ - Information/⁉️-questions/threads/anybody-thought-of-1-2-mm-slot-to-be-packaged-soic-8-package.md.

Category: ℹ️ - Information Parent channel: #⁉️-questions Thread ID: 1523053835864637510

Messages: 10

message-1523053835864637510

2026-07-04T19:52:11.442+00:00 — bobo38

Content

I was wandering whether it could be possible to fit 10 to 16 dies in a standard slot in order to go for SOIC-8 packaging. I got some idea about a standard pad frame placement for SOIC-8 packaging that could work with 1.5-2 mm² dies, likely with dedicated ESD protections. It could be very handy for people to implement stand-alone analog IC with 8 pins which allow a lot of classic discrete analog functions. SOIC-8 is easy to handle and solder, and there are inexpensive sockets available to test all your parts without soldering.

It seems that SOIC-8 packaging is much cheaper than QFN with large pin numbers. If we were able to dice 10 to 16 dies in a one slot, we could reduce cost and increase access for sub 1000$ entry level to get 1000 SOIC-8 parts. I would personally be interested in designing some op amp stuff, but current prices are too large for hobby. It might really interest some universities for educational program, or even some start-ups needed tailor made discrete IC in small quantities, or prototype new discrete IC product.

Wafer.space, what is the smallest die size that can be diced? 1 mm²? would you be willing to offer those?

If a community grows and organizes to fill slots, and wafer.space provides final standardized dies for SOIC-8, it could be possible to join orders and get that packaged many thousands of SOIC-8 at little cost. It would be much easier if wafer.space developed this capability directly. Would there be some interest for wafer.space to develop this offer?

For all: what do you think about that? Would you be interested in? Should the package size be increased to SOIC-16 to fit more stuff?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/1-B2132.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1523055715005104178

2026-07-04T19:59:39.464+00:00 — tnt (@246tnt)

Content

Do you have a link for packaging house doing soic cheap ?
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/88d17af9d19ab43565b0c46751ef7d12-DFEE5.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1523057235721322598

2026-07-04T20:05:42.031+00:00 — bobo38

Content

> • Selected Package: SOIC
> • Pins: 16pin
> • Volume: Low
>
> The estimate price is: $0.18
>
> Don’t hesitate to contact us if you have any questions.
Got by email by filling form on https://anysilicon.com/package-price-estimator/

Not sure whether it's possible to really get those prices for 10000-20000 parts. ChatGPT believes that the price for low volume is not so inflated, because those packages are very standard, and basically need 2 lines of pads with some pitch. The website does not have 8 pins.

Embeds

<details> <summary>Embeds data</summary>
[
  {
    "color": "#CD2727",
    "description": "<br />",
    "fields": [],
    "images": [],
    "inlineEmojis": [],
    "timestamp": null,
    "title": "IC Package Price Estimator - AnySilicon",
    "url": "https://anysilicon.com/package-price-estimator/"
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/1-B2132.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1524063900520284350

2026-07-07T14:45:49.622+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

@bobo38 - I have not found anyone who is willing to do the low volume that wafer.space has.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2026-07_media/1-B2132.png",
        "color": null,
        "discriminator": "0000",
        "id": "380027166936530945",
        "isBot": false,
        "name": "bobo38",
        "nickname": "bobo38",
        "roles": []
      }
    ]
  }
}
</details>

message-1524064395838230570

2026-07-07T14:47:47.715+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

@bobo38 - I started trying to figure out how to do IO only one one side of the die and such at https://mithro.github.io/gf180mcu-project-template/
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2026-07_media/1-B2132.png",
        "color": null,
        "discriminator": "0000",
        "id": "380027166936530945",
        "isBot": false,
        "name": "bobo38",
        "nickname": "bobo38",
        "roles": []
      }
    ]
  }
}
</details>

message-1524075766219014326

2026-07-07T15:32:58.625+00:00 — RebelMike (@rebelmike)

Content

I plan to submit a one side only quarter slot design as a test - @Leo Moser (mole99) did some changes to the template to allow that to work.  As you can see, this allows a decent amount of SRAM on a quarter slot (here 9.5kB):

Attachments

<details> <summary>Attachments data</summary>
[
  {
    "fileName": "chip_top.png",
    "fileSizeBytes": 4102648,
    "id": "1524075765879144669",
    "url": "2026-07_media/chip_top-B3536.png"
  }
]
</details>

Reactions

<details> <summary>Reactions data</summary>
[
  {
    "count": 1,
    "emoji": {
      "code": "heart",
      "id": "",
      "imageUrl": "2026-07_media/2764-A3D25.svg",
      "isAnimated": false,
      "name": "❤️"
    },
    "users": [
      {
        "avatarUrl": "2026-07_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
        "color": null,
        "discriminator": "0000",
        "id": "323371864074485771",
        "isBot": false,
        "name": "mole99",
        "nickname": "Leo Moser (mole99)"
      }
    ]
  }
]
</details><details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/49aaff687e56f04e7bbdedf0077bab75-7DDB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2026-07_media/3c7c17f3225f6e56f4dccd83f14383f2-73F83.png",
        "color": null,
        "discriminator": "0000",
        "id": "323371864074485771",
        "isBot": false,
        "name": "mole99",
        "nickname": "Leo Moser (mole99)",
        "roles": [
          {
            "color": null,
            "id": "1423020172595298314",
            "name": "Mod",
            "position": 4
          }
        ]
      }
    ]
  }
}
</details>

message-1524117617588310199

2026-07-07T18:19:16.769+00:00 — bobo38

Reply/reference

<details> <summary>Reference data</summary>
{
  "channelId": "1523053835864637510",
  "guildId": "1361349522684510449",
  "messageId": "1524064395838230570"
}
</details>

Content

yeah maybe just one edge with IO would allow low pin count small dies. @RebelMike , I would rather remove the corner cells, as they only make sense to connect an adjacent edge I would say
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/1-B2132.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2026-07_media/9679bb77da48d47c905b398d98a83780-75B68.png",
        "color": null,
        "discriminator": "0000",
        "id": "169786952432746498",
        "isBot": false,
        "name": "mithro_",
        "nickname": "Tim 'mithro' Ansell",
        "roles": []
      },
      {
        "avatarUrl": "2026-07_media/49aaff687e56f04e7bbdedf0077bab75-7DDB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "691780627338625077",
        "isBot": false,
        "name": "rebelmike",
        "nickname": "RebelMike",
        "roles": []
      }
    ]
  }
}
</details>

message-1524120847797719120

2026-07-07T18:32:06.911+00:00 — RebelMike (@rebelmike)

Content

Yeah, that would make sense, I haven’t looked into how this actually works in the pad ring script.
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/49aaff687e56f04e7bbdedf0077bab75-7DDB4.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {}
}
</details>

message-1524221314611806439

2026-07-08T01:11:20.066+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

@RebelMike - Oh, super cool!
<details> <summary>Other message metadata</summary>
{
  "author": {
    "avatarUrl": "2026-07_media/9679bb77da48d47c905b398d98a83780-75B68.png",
    "discriminator": "0000",
    "isBot": false
  },
  "message": {
    "mentions": [
      {
        "avatarUrl": "2026-07_media/49aaff687e56f04e7bbdedf0077bab75-7DDB4.png",
        "color": null,
        "discriminator": "0000",
        "id": "691780627338625077",
        "isBot": false,
        "name": "rebelmike",
        "nickname": "RebelMike",
        "roles": []
      }
    ]
  }
}
</details>

message-1524222006034174083

2026-07-08T01:14:04.914+00:00 — Tim 'mithro' Ansell (@mithro_)

Content

@bobo38 - Most people complain about not having enough I/O, so I'm excited for people who think they can do something with the much more limited 12 or 20 I/O count.

I think of 12 I/O as 2 power, 8 bit bidir bus and 2 control while 20 I/O is 16 bit bidir.

Packaging is about 1-2 cents a pin + some fixed cost (around ~10-15 cents), so with something like 12 I/O we might be able to get packaging down to $0.50 each.
